ROFLEX SEALING GROMMETS

SKU 13608
AU$27.72
In stock
1
Product Details


Applications

Airtight sleeves for sealing around pipes and ducts.

Dimensions

ROFLEX 50 - 140mm x 140mm - fits pipes with outside diameter 50mm to 90mm

ROFLEX 100 - 200mm x 200mm - fits pipes with outside diameter 100mm to 120mm

ROFLEX 150 - 250mm x 250mm - fits pipes with outside diameter 120mm to 170mm

ROFLEX 200 - 300mm x 300mm - fits pipes with outside diameter 170mm to 220mm

ROFLEX 250 - 450mm x 450mm - fits pipes with outside diameter 220mm to 270mm

ROFLEX 300 - 500mm x 500mm - fits pipes with outside diameter 270mm to 320mm

Advantages

  • Airtight sleeves made from EPDM and TESCON VANA for fast and secure application
  • Makes quick durable airtight connections to cables, wires or pipes that enter through airtight membranes
  • Pre punctured flexible EPDM provides a tight fitting sleeve, without causing a protruding bulge
  • Pipe remains adjustable after installation

Properties

  • Penetrations: for one pipe pass-troughs
  • Material: EPDM rubber gasket with TESCON VANA air sealing tape
  • For air-tight sealing according DIN 4108-7 (ACH50 < 1.5)
  • NBC 2015 - 5.4.1 Air Barrier Systems: Passed air leakage <0.02 L/(s·m²) @75 Pa (ASTM E2178)
